Super Duct Auto Line V

The linear structure of machine makes processing smoothly and occupies a small space. All the rolling reels are made of bearing steel so that the lifetime prolongs by more than 5 times. Under the material-saving mode of CNC system, waste is less than 20mm per roll.

Description

  • The linear structure of machine makes processing smoothly and occupies a small space.
  • All the rolling reels are made of bearing steel so that the lifetime prolongs by more than 5 times.
  • Under the material-saving mode of CNC system, waste is less than 20mm per roll.
  • The injection holes are used at both ends of the drive shaft, to enhance the bearing life.
  • Power bending function is used to prevent generating the waste and make sure perfect bending accuracy.
  • It requires at least one person to operate and each shift can output 600-2000.
  • With production memory functions, the production orders can be tracked and checked.

  • Cylinder imported from Germany Festo
  • Beijing Huade plus hydraulic system from Taiwan
  • Japan Omron encoder
  • Taiwan HIWIN linear guideways
  • Taiwan Delta CNC system

Basic Configuration

  • Two electric coil cradles, 4 material trays ( 5-7t each roll)
  • One rack
  • One hose (line 2 host)
  • One mechanical arm clutching, locating and transferring platform
  • One displacement type locking machine
  • One duplex TDF flange forming machine
  • One duplex angle steel flange forming machine
  • One servo feeding platform
  • One hydraulic folding machine
  • One set of computer controlling system

Function

It’s mainly for TDF/angle steel/ C-shaped flange forming with the daily processing capability of 60-2000 square meters, Only with inputting dimensions in the duct, the production line can automatically complete uncoiling, leveling, beading, punching, shearing, locking, forming TDF/angle steel/C-shaped flange and folding.

Working Schematic Diagram

Work Flow

Customer care

When you buy an Artizono machine, you’re buying a high-performance machine tool. To us, customer care is all about ensuring that we maintain that high performance for each and every one of our customers, no matter what it takes.

Technical spec.

Downloading our product brochure to learn more about the specific technical parameters of the machine.

Innovative Capacity

Strong techinical R&D force made Dachang a legacy. Dachang invented and applied 10+ patents, yet innovation never stops.

Standardized Production

Specialized production line, well-functioned components, experienced technicians together creates a sophisticated machine.

QC Management

No machine will be delivered until it reaches each standard of each QC process. You get only the capacity boosting machines.

Prioritized Customers' Need

Feel free to contact us or visit our plant at any time to convey your accurate production need, then wait to be satisfied.

Prompt Delivery

No matter you order 1 or a batch of machines, we have them delivered to you on time, intact.

Quality Guaranty

We assure you a stable quality. Yet if there is breakdown, which is rare, we provide 1 year of guaranty and on-site solution as appropriate.
